Kinney KTC 112 Rotary Piston Vacuum Pump - NEW

Recommended for applications where operating pressure is below 0.1 Torr (0.13 mbar)
Achieve lowest possible pressures from mechanical pumps
Rugged and reliable
No metal-to-metal contact between pump piston & cylinder - clearances are filled with oil
Unequaled durability, even in dirty applications

Motor Power (hp): 7.50

- [ ]

Ultimate Pressure (Torr): 0.0002

- [ ]

Pumping Speed (cfm): 107

Kinney is now part of MD-Kinney, which was formerly known as Tuthill Springfield.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

	UNIT	MODEL
	UNIT	KTC-21	KTC-60	KTC-112
Nominal Displacement at Rated RPM	CFM / *m³/h*	21 / 36	60 / *102*	107 / *182*
Motor	HP / kW	1.5 / *1.1*	3 / *2.2*	7.5 / *5.6*
Motor Speed	RPM	1725	960	1060
Cooling Water Required	GPM / *L/min*	—	—	1.5 / *5.7*
Oil Capacity	Quarts / *Liters*	2.0 / *1.9*	8.0 / *7.6*	16.0 / *15.1*
Pump Weight	Lbs. / kg	190 / 86	515 / *234*	880 / *399*
Maximum Gas Ballast Flow	%	10	10	10
Gas Ballast Pressure	Torr (mm Hg abs.)	.020	.020	.020
Ultimate Pressure	Torr	2 × 10^-4	2 × 10^-4	2 × 10^-4
Noise Level at 0.1 Torr	dB(A)	72	70	70

Type	Label	Description	Download
	Kinney KTC 60 & 112 - NEW	OPERATOR'S MANUAL	Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Kinney KTC 112 Rotary Piston Vacuum Pump - NEW

KTC21   21 cfm / 36 m³/h
KTC60   60 cfm / 102 m³/h
KTC112   107 cfm / 182 m³/h
