Leybold CVS1000 - NEW
Weight
2447 lbs
Motor Power
22 hp
Pumping Speed
720 m³ /h
Ultimate Pressure
≤ 8 x 10-2 mbar
Leybold CVS1000 - 3XSV300B FF Vacuum Pump - NEW
SOGEVAC Central Vacuum Stations cover the demands of numerous small vacuum consumers, increasing the availability of the vacuum service. They provide the essential performance and reliability to succeed under challenging production conditions. Questions? send an email to our sales team!
Volume vacuum vessel:
1000 l
Installed vacuum pump:
3 x SOGEVAC SV 300 B
Inlet connection vacuum vessel:
G 2", Inside thread
Outlet connection:
G 2", Inside thread
Nominal pumping speed at 50 Hz:
840 m³/h
Nominal pumping speed at 60 Hz:
1020 m³/h
Pumping speed at 50 Hz:
720 m³/h
Pumping speed at 60 Hz:
870 m³/h
Ultimate total pressure without gas ballast:
≤ 0.08 mbar
Ultimate total pressure with gas ballast:
≤ 0.7 mbar
Water vapor tolerance at 50 Hz:
10 mbar
Water vapor tolerance at 60 Hz:
12 mbar
Water vapor capacity at 50 Hz:
3900 g/h
Water vapor capacity at 60 Hz:
5400 g/h
Operating fluid:
LVO 130
Operating fluid capacity:
33 l
Noise level to DIN 45 635:
77 dB(A), without gas ballast
Mains connection:
3-ph, 400 V, 50 Hz // 460 V, 60 Hz
Installed motor rating at 50 Hz:
16.5 kW
Installed motor rating at 60 Hz:
19.8 kW
Electrical control:
Full Feature-Controller
Admissible ambient temperature:
+12 to +40°C
Dimensions (LxBxD):
2379 x 1159 x 1690 mm
Weight:
1110 kg / 2447 lbs
Specifications
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold CVS1000 - 3XSV300B FF Vacuum Pump - NEW
