Leybold SOGEVAC SV300B - REBUILT

$9,915
In stock
SKU
REBUILT_SV300B
Weight 492 lbs
Motor Power 7.38 hp
Pumping Speed 240 m3/h
Ultimate Pressure ≤ 8 x 10-2 mbar

Leybold SOGEVAC SV300B Rotary Vane Vacuum Pump - REBUILT

PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service for your used vacuum pumps. View the other SOGEVAC B models.

  • Operating fluid: LEYBONOL LVO 130
  • Pumping speed (50 Hz): 240 m³/h
  • Pumping speed (60 Hz): 290 m³/h
  • Ultimate pressure: 0.08 mbar

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Nominal Speed
    50 Hz 280 m3 x h-1
    60 Hz 340 m3 x h-1
Pumping speed
    50 Hz 240 m3 x h-1
    60 Hz 290 m3 x h-1
Ultimate partial pressure w/out gas ballast ≤ 8 x 10-2 mbar
Ultimate total pressure w/ gas ballast ≤ 0.7 mbar
Water vapor tolerance with standard gas ballast
    50 Hz 30 mbar
    60 Hz 40 mbar
Water vapour tolerable load with gas ballast
    50 Hz 5.4 kg x h-1
    60 Hz 7.4 kg x h-1
Water vapour tolerance with big gas ballast
    50 Hz 60 mbar
    60 Hz 70 mbar
Water vapour tolerable load with big gas ballast
    50 Hz 10 kg x h-1
    60 Hz 12.5 kg x h-1
Leak rate ≤ 1 x 10-3
Noise level 70 dBA
Mains voltage 230/400 V
Motor power 5.5 kW
rated rotational speed 1,450 min-1
Type of protection IP 55
Weight 223 kg / 492 lbs
Connections
Intake, thread 3/4" G or NPT

Specifications

Type Label Description Download
Leybold SOGEVAC SV 200 & 300 - REBUILT Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold SOGEVAC SV300B Rotary Vane Vacuum Pump - REBUILT

Part no. 960700 / 960 700
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
Three-phase motor: 230/400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz
w/out gas ballast valve - w/ oil filter

Part no. 960701 / 960 701
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 230/400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz
w/ small gas ballast valve - w/ oil filter

Part no. 960706 / 960 706
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 208V, +/- 10% / 230/460V, +/- 10%, 60Hz // 400V, +/- 10%, 50Hz
w/ small gas ballast valve - w/ oil filter

Part no. 960711V / 960 711V
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, + 10%, - 15%, 50/60Hz
w/ small gas ballast valve - w/ oil filter

Part no. 960702 / 960 702
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 230/400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz
w/ standard gas ballast valve - w/ oil filter

Part no. 960707 / 960 707
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 208V, +/- 10% / 230/460V, +/- 10%, 60Hz // 400V, +/- 10%, 50Hz
w/ standard gas ballast valve - w/ oil filter

Part no. 960712 / 960 712
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, + 10%, - 15%, 50/60Hz
w/ standard gas ballast valve - w/ oil filter

Part no. 960703 / 960 703
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 230/400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz
w/ big gas ballast valve - w/ oil filter

Part no. 960708 / 960 708
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 208V, +/- 10% / 230/460V, +/- 10%, 60Hz // 400V, +/- 10%, 50Hz
w/ big gas ballast valve - w/ oil filter

Part no. 960713V / 960 713V
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, + 10%, - 15%, 50/60Hz
w/ big gas ballast valve - w/ oil filter

Part no. 960716V / 960 716V
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz, CTP, 5.5 KW & 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz, CTP, 6.6 kW
w/ small gas ballast valve - w/ oil filter

Part no. 960717 / 960 717
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz, CTP, 5.5 KW & 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz, CTP, 6.6 kW
w/ standard gas ballast valve - w/ oil filter

Part no. 960718 / 960 718
Pumping speed: 240 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz, CTP, 5.5 KW & 200V, -15%, bis 230V, +10% / 380 - 400V, +/- 10%, 50Hz // 460V, +/- 10%, 60Hz, CTP, 6.6 kW
w/ big gas ballast valve - w/ oil filter

Operating fluid: LEYBONOL LVO 130
