Leybold RUVAC WAU 1001 H - REBUILT
Call for Price
| Weight | 496 lbs |
|---|---|
| Motor Power | 4 hp |
| Pumping Speed | 1,000 m3/h |
| Ultimate Pressure | 8 x 101 mbar |
Leybold RUVAC WAU 1001 H Roots Vacuum Blower - REBUILT
The Leybold RUVAC WAU 1001 H is a high-performance single-stage Roots vacuum pump designed to deliver exceptional pumping speeds and reliable operation in demanding industrial and scientific applications. This pump is part of the renowned RUVAC WAU series, known for its robust construction, efficient performance, and versatility.
Key Features:
- High Pumping Speed: The RUVAC WAU 1001 H offers a high pumping speed, making it ideal for applications requiring rapid evacuation of large volumes of gas.
- Integrated Pressure Balance Line: The WAU series includes a pressure balance line between the discharge and intake flange, ensuring smooth operation and enhanced performance across a wide pressure range.
- Compact Design: With its optimized dimensions and lightweight construction, the pump is easy to integrate into existing systems without requiring significant modifications.
- Durable Construction: Built with high-quality materials such as cast iron and steel, the WAU 1001 H is designed to withstand harsh operating conditions and provide long-lasting performance.
- Quiet Operation: Engineered for low noise levels, the pump ensures a quieter working environment, even during extended operation.
- Versatile Applications: Suitable for a wide range of applications, including vacuum coating, semiconductor manufacturing, chemical processing, and more.
The Leybold RUVAC WAU 1001 H is an excellent choice for industries requiring high pumping speeds and reliable vacuum performance. Typical applications include:
- Vacuum furnaces
- Freeze drying
- Pharmaceutical production
- Research and development laboratories
- Thin-film deposition processes
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal pumping speed | 50 Hz: 1,000 m3 x h-1 | 60 Hz: 1,200 m3 x h-1 |
| Max. effective pumping speed w/ backing pump | 50 Hz: 800 m3 x h-1 | 60 Hz: 1,000 m3 x h-1 |
| Ultimate total pressure | < 4 x 10-2 | |
| Max. permissible pressure difference during continuous operation | 80.0 mbar | |
| Leak rate, integral | < 5 x 10 -4 mbar x l/s | |
| Mains supply | 50 Hz: 200-240 V, 380-400 V | 60 Hz: 200-240 V, 380-480 V |
| Thermal class | F | |
| Permissible ambient temperatures | +5 to +40°C | |
| Motor power | 4.0 kW | |
| Energy efficiency class | IE 2 | |
| Nominal speed, approx. | 50 Hz: 3,000 rpm | 60 Hz: 3,600 rpm |
| Max. permissible speed | 3,600 rpm | |
| Type of protection | IP 55 | |
| Connection flanges | DN 100 ISO-K | |
| Nominal rotation speed at 60 Hz | 3,600 min-1 / 3,600 rpm | |
| Max. permissable rotation speed | 3,600 min-1 / 3,600 rpm | |
| Motor protection rating | IP 55 | |
| Noise level | < 70 dB(A) | |
| Weight | 220/225 kg / 485 / 496 lbs |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold RUVAC WA / WAU Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUVAC WAU 1001 H Roots Vacuum Blower - REBUILT Part no. 11841 / 118 41 Pumping speed: 1,000 m3/h Ultimate pressure: < 4 x 10-2 mbar 3-phase motor: 220-240/380-420V, 50Hz / 250-277/400-480V, 60Hz
