Leybold SOGEVAC SV 1200 - NEW
Call for Price
In stock
SKU
NEW_SV1200
| Weight | 3200 lbs |
|---|---|
| Motor Power | 30 hp |
| Pumping Speed | 1,070 m3/h |
| Ultimate Pressure | ≤ 1 x 10-1 mbar |
Leybold SOGEVAC SV 1200 Rotary Vane Vacuum Pump - NEW
The standard version of the SOGEVAC rotary vane pump series is suitable for rough industrial applications which can be customized to fit individual customer needs. A wide range of monitoring accessories and options are available. Different motor versions, inlet or exhaust ports, food-grade oil, food-grade paint, larger gas ballast are some examples of possible customizing
- Operating fluid: LEYBONOL LVO 130
- Pumping speed (50 Hz): 1,070 m³/h
- Pumping speed (60 Hz): 1,070 m³/h
- Ultimate pressure: 0.1 mbar
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal pumping speed | 50 Hz: 1,150 m3h-1 | 60 Hz: 1,150 m3h-1 |
| Pumping speed | 50 Hz: 1,070 m3h-1 | 60 Hz: 1,070 m3h-1 |
| Ultimate total pressure w/ gas ballast | 50 Hz: ≤ 1.5 mbar | 60 Hz: ≤ 1.5 mbar |
| Ultimate total pressure w/out gas ballast | 50 Hz: ≤ 0.1 mbar | 60 Hz: ≤ 0.1 mbar |
| Water vapor tolerance | 20 mbar | 15 Torr |
| Oil capacity | 70 l | |
| Nominal speed | 50 Hz: 1,460 rpm | 60 Hz: 1,750 rpm |
| Motor power | 22 kW | |
| Noise level | 75 dB(A) | |
| Weight | 1,450 kg |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV 1200 Rotary Vane Vacuum Pump - NEW Part no. 10970 / 109 70 Pumping speed: 1,070 m3/h Ultimate pressure: < 0.1 mbar Three-phase motor: 400V, 50Hz Part no. 95070 / 950 70 Pumping speed: 1,070 m3/h Ultimate pressure: < 0.1 mbar 3-phase motor: 208-230/460V, 60Hz w/ gas ballast valve Operating fluid: LEYBONOL LVO 130
