Leybold SOGEVAC SV200 - REBUILT
Weight
353 lbs
Motor Power
5.36 hp
Pumping Speed
170 m3 /h
Ultimate Pressure
≤ 8 x 10-2 mbar
Leybold SOGEVAC SV200 Rotary Vane Vacuum Pump - REBUILT
The standard version of the SOGEVAC rotary vane pump series is suitable for rough industrial applications which can be customized to fit individual customer needs. A wide range of monitoring accessories and options are available. Different motor versions, inlet or exhaust ports, food-grade oil, food-grade paint, larger gas ballast are some examples of possible customizing.
Questions? send an email to our sales team!
Pumping speed
50 Hz
170 m3 x h-1
60 Hz
200 m3 x h-1
Ultimate total pressure w/out gas ballast
50 Hz
≤ 8 x 10-2 / ≤ 6 x 10-2 Torr
60 Hz
≤ 8 x 10-2 / ≤ 6 x 10-2 Torr
Ultimate total pressure w/ gas ballast
50 Hz
≤ 0.7 mbar / ≤ 0.5 Torr
60 Hz
≤ 0.7 mbar / ≤ 0.5 Torr
Water vapor tolerance
w/ standard gas ballast
50 Hz: 30 mbar / 22.5 Torr
60 Hz: 40 mbar / 30 Torr
w/ big gas ballast
50 Hz: 50 mbar / 37.5 Torr
60 Hz: 50 mbar / 37.5 Torr
Water vapor capacity
w/ standard gas ballast
50 Hz: 3.4 kg x h-1 / 3.6 hr
60 Hz: 5.4 kg x h-1 / 5.7 hr
Oil capacity, min / max
5 l / 9 l
Noise level
50 Hz: 69 dBA / 60 Hz: 73 dBA
Admissible ambient temperature
12 to 40 °C / 54 to 104 °F
Motor power
4.0 kW
Nominal speed
1,450 min-1
Type of protection
IP 55
Weight
160 kg / 353 lbs
Specifications
Type
Label
Description
Download
Leybold SOGEVAC SV 200 & 300 - REBUILT
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV200 Rotary Vane Vacuum Pump - REBUILT
95027 / 950 27
955279900001TE
