Leybold TRIVAC D30A - REBUILT
Weight
163 lbs
Motor Power
1.5 hp
Pumping Speed
760 l/m
Ultimate Pressure
3 x 10-4 Torr
Leybold TRIVAC D30A Rotary Vane Vacuum Pump - REBUILT
If the requested voltage is not in stock then we will purchase a new motor and split the cost with you. They run on various vacuum pump oils . PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service . We also provide the TRIVAC corrosive models (D2AC, D4AC, D8AC, D16AC, D30AC, D60AC, D90AC).
Leybold blower packages are available.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
Displacement
26.8 cfm
760 l/min
Ultimate partial pressure
3 x 10-4 Torr
Ultimate partial pressure w/ gas ballast
3 x 10-3 Torr
Water vapor tolerance
40 Torr
Oil capacity
3.5 qt
13.7 lbs
Motor power
11/2 hp
Rotational speed
1,725 rpm
Weight
163 lb
Sound pressure level (max) at 3 feet w/ gas ballast open
59 dB(A)
Sound pressure level (ave) at 3 feet w/ gas ballast open
62 dB(A)
Intake & exhaust connections
KF40
Max. ambient temperature
104°F
Specifications
Type
Label
Description
Download
Leybold-Heraeus TRIVAC A Series - REBUILT
Operating Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TRIVAC D30A Rotary Vane Vacuum Pump - REBUILT
898041
898043
89585
302543
