Pfeiffer Adixen Alcatel 2015C2 - REBUILT
Weight
59.5 lbs
Pumping Speed
10.6 cfm
Ultimate Pressure
2.25 x 10-3 torr
Pfeiffer Adixen Alcatel 2015C2 Pascal Rotary Vane Vacuum Pump - REBUILT
Rebuilt with one year warranty. Pfeiffer Adixen Alcatel 2015C2 Pascal rotary vane vacuum pumps. These have dual voltage: 115-230V motors and have a manual gas ballast. Fill out our request for quote form.
Questions? send an email to our sales team!
Specifications
Unit
2010C2
2015C2
2021C2
Frequency
Hz
50
60
50
60
50
60
Number of stages
2
Rotation speed
rpm
1,500
1,800
1,500
1,800
1,500
1,800
Nominal pumping speed
m3 /h (cfm)
9.7
11.6 (6.8)
15
18 (10.6)
20.7
24.8 (14.6)
Pneurop pumping speed
m3 /h (cfm)
8.5
10.2 (6)
12.5
15 (8.8)
16.5
20 (11.8)
Max. pumping speed
m3 /h
9.7
11.6
15
18
20.7
24.8
Max. gas throughput
mbar l/s
2,722
3,263
4,222
5,063
5,833
6,977
Emission sound pressure level without gas ballast
dB(A)
< 52
< 54
< 53
< 54
< 53
< 55
Partial ultimate pressure
Torr / mbar / Pa
3.75 x 10-4 / 5 x 10-4 / 5 x 10-2
Ultimate pressure with gas ballast closed
Torr / mbar / Pa
2.25 x 10-3 / 3 x 10-3 / 3 x 10-1
Max. pressure at inlet in continuous operation
Torr / mbar / Pa
< 8 / 10 / 1 x 10-3 w/out oil recovery-4 w/ oil recovery
Oil capacity
liters
0.95
0.98
Weight (pump + motor)
kg (lbs)
26 (57)
27 (59.5)
28 (62)
Inlet and outlet, Pneurop nipples
DN 25 ISO-KF
Specifications
Type
Label
Description
Download
Pfeiffer Adixen Pascal Series - REBUILT
Operating Instructions
Download
Alcatel Pascal Series - REBUILT
User's Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
