Pfeiffer HiPace 700 - REBUILT
| Weight |
30 lbs |
| Pumping Speed |
685 l/s |
| Ultimate Pressure |
1 x 10-7 mbar |
Pfeiffer Vacuum HiPace 700 Turbomolecular Pump - REBUILT
- Minimum footprint and maximum reliability
- High gas throughput and high pumping speed
- Suitable for industrial environments - Protection class IP54
- Semi S2 and UL/CSA certification
- Monitoring of operating data
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Bearing |
Hybrid |
| Compression ratio |
|
| Ar |
> 1 x 1011 |
| H2 |
4 x 105 |
| He |
3 x 107 |
| N2 |
> 1 x 1011 |
| Cooling method, optional |
Air |
| Cooling method, standard |
Water |
| Cooling water consumption |
100 l/h |
| Cooling water temperature |
15-35°C / 59-95°F / 288-308°K |
| Electronic drive unit |
w/ TC 400 |
| Flange (in) |
DN 160 ISO-K |
| Flange (out) |
DN 25 ISO-KF / G 1/4" |
| Fore-vacuum max. for N2 |
11 hPa / 8.25 Torr / 11 mbar |
| Gas throughput at full rotational speed for Ar |
3.5 hPa l/s / 2.62 Torr l/s / 3.5 mbar l/s |
| Gas throughput at full rotational speed for H2 |
> 14 hPa l/s / > 10.5 Torr l/s / > 14 mbar l/s |
| Gas throughput at full rotational speed for He |
20 hPa l/s / 15 Torr l/s / 20 mbar l/s |
| Gas throughput at full rotational speed for N2 |
6.5 hPa l/s / 4.88 Torr l/s / 6.5 mbar l/s |
| Interfaces |
RS-485, Remote |
| Mounting orientation |
in any orientation |
| Operating voltage |
48 (± 5%) V DC |
| Permissible magnetic field max. |
6 mT |
| Protection category |
IP54 |
| Pumping speed for Ar |
665 l/s |
| Pumping speed for H2 |
555 l/s |
| Pumping speed for He |
655 l/s |
| Pumping speed for N2 |
685 l/s |
| Rotation speed ± 2 % |
49,200 min-1 |
| Rotation speed variable |
60-100% |
| Run-up time |
2 min |
| Sound pressure level |
≤ 50 dB(A) |
| Ultimate pressure according to PNEUROP |
< 1 x 10-7 hPa / < 7.5 x 10-8 Torr / < 1 x 10-7 mbar |
| Venting connection |
G 1/8" |
| Weight |
11.5 kg / 25.35 lb |
Specifications
| Type |
Label |
Description |
Download |
|
|
Pfeiffer HiPace 700 - REBUILT |
Operating Instructions |
Download
|
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Vacuum HiPace 700 Turbomolecular Pump - REBUILT
PMP03933 / PM P03 933 w/ TC 400 DN 160 ISO-K
PMP03934 / PM P03 934 w/ TC 400 DN 160 CF-F
PMP03935 / PM P03 935 w/ TC 400 DN 160 ISO-F
PMP04080 / PM P04 080 for TCP 350 DN 160 ISO-K
PMP04081 / PM P04 081 for TCP 350 DN 160 CF-F
PMP04082 / PM P04 082 for TCP 350 DN 160 ISO-F
PMP04253 / PM P04 253 w/ TC 400 Profibus DN 160 ISO-K
PMP04254 / PM P04 254 w/ TC 400 Profibus DN 160 CF-F
PMP04255 / PM P04 255 w/ TC 400 Profibus DN 160 ISO-F
PMP04275 / PM P04 275 w/ TC 400 DN 160 ISO-K
PMP04681 / PM P04 681 w/ TC 400 DN 160 CF-F
PMP04680 / PM P04 680 w/ TC 400 DN 160 ISO-F
PMP04440 / PM P04 440 w/ TC 400 DN 160 ISO-K
PMP04441 / PM P04 441 w/ TC 400 DN 160 CF-F
PMP04442 / PM P04 442 w/ TC 400 DN 160 ISO-F
