Pfeiffer HiPace 80 Neo - NEW

Name: Pfeiffer HiPace 80 Neo - NEW
Brand: Pfeiffer
SKU: NEW_HiPace80Neo

Be the first to review this product

Call for Price

In stock

SKU

NEW_HiPace80Neo

Request For Quote

Weight	3.75 lbs
Pumping Speed	35 l/s
Ultimate Pressure	1 x 10^-7 mbar

Description

Pfeiffer Vacuum HiPace 80 Neo Turbomolecular Pump - NEW

Features include:

Small yet powerful turbo pump with a pumping speed of up to 35 l/s for N₂
TC 80 integrated electronic drive unit
For installation in any orientation
Ideal for dependable systems integration
Extensive accessories expand the range of applications

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

I/O interfaces	RS485, remote
Sound pressure level (EN ISO 2151)	48 dB(A)
Run-up time	1.25 min
Pumping speed for Ar	66 l/s
Pumping speed for H₂	48 l/s
Pumping speed for He	58 l/s
Pumping speed for N₂	67 l/s
Gas throughput at final rotational speed for Ar	0.54 hPa x l/s
Gas throughput at final rotational speed for H₂	15.3 hPa x l/s
Gas throughput at final rotational speed for He	2.7 hPa x l/s
Gas throughput at final rotational speed for N₂	1.3 hPa x l/s
Compression ratio for Ar	1 x 10¹¹
Compression ratio for H₂	1.4 x 10⁵
Compression ratio for He	1.3 x 10⁷
Compression ratio for N₂	1 x 10¹¹
Forevacuum max. for N₂	22 hPa (mbar)
Mounting orientation	Arbitrary
Weight	1.7 kg
Gas inlet / outlet	DN40/DN 63 ISO-K/ISO-KF/CF-F / G 1/4"

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Pfeiffer Vacuum HiPace 80 Neo Turbomolecular Pump - NEW

                               (BUSCH P/N)
PMP08026110 / PM P080 261 10 / 2000013615  HiPace 80 Neo  TC 80, DN 40 ISO-KF
PMP08026610 / PM P080 266 10 / 2000013618  HiPace 80 Neo  TC 80, DN 40 ISO-KF, G 1/4"
PMP08S26110 / PM P08S 261 10 / 2000205487  HiPace 80 Neo  TC 80, DN 40 ISO-KF, Sealing gas version
PMP08031110 / PM P080 311 10 / 2000013626  HiPace 80 Neo  TC 80, DN 63 CF-F
PMP08031610 / PM P080 316 10 / 2000013629  HiPace 80 Neo  TC 80, DN 63 CF-F, G 1/4"
PMP08S31610 / PM P08S 316 10 / 2000205464  HiPace 80 Neo  TC 80, DN 63 CF-F, G 1/4", Sealing gas version
PMP08S31110 / PM P08S 311 10 / 2000103219  HiPace 80 Neo  TC 80, DN 63 CF-F, Sealing gas version
PMP08030110 / PM P080 301 10 / 2000013620  HiPace 80 Neo  TC 80, DN 63 ISO-K
PMP08030610 / PM P080 306 10 / 2000013623  HiPace 80 Neo  TC 80, DN 63 ISO-K, G 1/4"
PMP08S30110 / PM P08S 301 10 / 2000184964  HiPace 80 Neo  TC 80, DN 63 ISO-K, Sealing gas version
