Pfeiffer TPH 330 - REBUILT
| Weight |
93 lbs |
| Pumping Speed |
300 l/s |
| Ultimate Pressure |
1 x 10-11 torr |
|---|
Pfeiffer Balzers TPH 330 Turbomolecular Vacuum Pump - REBUILT
We offer repair service and are capable of rebuilding, balancing and testing this pump.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet |
DN 100 ISO-K |
| Outlet |
DN 25 KF |
| Volume flow rate for (l/s) |
|
| N2 |
300 |
| He |
370 |
| H2 |
330 |
| Compression ratio |
|
| N2 |
109 |
| He |
3 x 104 |
| H2 |
1.7 x 103 |
| Running (l/m) |
60,000 |
| Standby (l/m) |
40,000 |
| Cooling standard |
Water |
| Weight |
42kg / 93 lbs |
Specifications
| Type |
Label |
Description |
Download |
|
|
Pfeiffer TPH/TPU 330 & 510 - REBUILT |
Operating Instructions |
Download
|
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Balzers TPH 330 Turbomolecular Vacuum Pump - REBUILT
PMP01230 / PM P01 230 TPH 330 DN 100 ISO-K top flange
PMP01231 / PM P01 231 TPH 330 DN 100 ISO-K side flange
