Polycold MaxCool 2500 L - REBUILT
Call for Price
In stock
SKU
RB_MaxCool2500L
Brooks Polycold Systems MaxCool 2500 L Cryochiller - REBUILT
Edwards brands the recent Polycold cryochiller as the MaxCool 2500 L. Water vapor is condensed on a baffle that freezes until the next vent cycle. It provides 2,500 Watts of cooling at -120 C Questions?
| Specifications | MaxCool 2000 | MaxCool 2500 L | MaxCool 4000 H |
|---|---|---|---|
| Maximum cooling capacity | 2,000 W | 2,500 W | 4,000 W |
| Temperature at maximum cooling capacity | -111°C | -120°C | -98°C |
| Coldest temperature | -142°C | -145°C | -133°C |
| Ultimate operating pressure (25% of max pumping speed) | 3E-9 Torr | 8E-10 Torr | 5E-8 Torr |
| Typical cold trap area | 1.1 m2 | 1.4 m2 | 2.2 m2 |
| Maximum water vapor pumping speed from typical cold trap area | 163,900 l/s | 208,600 l/s | 327,800 l/s |
| Conservative maximum cold trap area* | 1.5 m2 | 2.0 m2 | 2.8 m2 |
| Electrical consumption (standby mode) | 5.5 kW | 11.4 kW | 12.0 kW |
| Electrical consumption (cool mode, typical load) | 6.2 kW | 13.9 kW | 12.4 kW |
| Electrical consumption (cool mode, max load) | 8.8 kW | 19.2 kW | |
| Cooling water flow for 13°C | 6.8 l/min | 15.1 l/min | |
| Cooling water flow for 18°C | 9.1 l/min | 18.2 l/min | |
| Cooling water flow for 24°C | 13.6 l/min | 27.3 l/min | |
| Cooling water flow for 29°C | 27.6 l/min | 54.1 l/min | |
| European PED-compliant | Yes | ||
| Nontoxic refrigerants | Yes | ||
| Non-flammable refrigerants | Yes | ||
| Type | Label | Description | Download |
|---|---|---|---|
|
Polycold MaxCool 2500L Data Sheet | Polycold MaxCool 2500L Data Sheet | Download |
|
Polycold MaxCool Series - REBUILT | Installation & Operation Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Brooks Polycold Systems MaxCool 2500 L Water Vapor Cryochiller - REBUILT Edwards MaxCool 2500L B 1CKT 460V input Edwards MaxCool 2500L B 2CKT 460V input
Related Products
-
Polycold MaxCool XC-8800 - REBUILTCall for Price
-
